BMW 3 Series Gran Turismo, technical data

THE BMW 3 SERIES GRAN TURISMO.

Technical data.

THE BMW 3 SERIES GRAN TURISMO.Technical data.

TECHNICAL DATA OF THE BMW 3 SERIES GRAN TURISMO.

Weight

Unladen weight EU in kg 1,675
Max. permissible weight in kg 2,170
Permitted load in kg 570
Permitted axle load front/rear in kg 975/1,255
Luggage capacity min. (seats up or roof down) in l 520
Luggage capacity max. (seats down or roof up) in l 1,600
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,500
Trailer load unbraked in kg 750

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
Engine torque (Nm) at 1/min 270/1,350-4,600
Compression ratio : 1 11.0

Performance

Top speed in km/h 229
Acceleration 0–100 km/h in s 8.1

Fuel consumption

Urban in l/100 km 7.8-7.7
Extra–urban in l/100 km 5.4-5.3
Combined in l/100 km 6.3-6.2
CO2 combined emissions in g/km 143-141
Tank capacity, approx. in l 60

Wheels

Tyre dimensions front 225/55 R17 97 V
Tyre dimensions rear 225/55 R17 97 V
Wheel dimensions and material front 8 J x 17 inches, light-alloy
Wheel dimensions and material rear 8 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,750
Max. permissible weight in kg 2,245
Permitted load in kg 570
Permitted axle load front/rear in kg 1,040/1,275
Luggage capacity min. (seats up or roof down) in l 520
Luggage capacity max. (seats down or roof up) in l 1,600
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,700
Trailer load unbraked in kg 750

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
Engine torque (Nm) at 1/min 270/1,350-4,600
Compression ratio : 1 11.0

Performance

Top speed in km/h 224
Acceleration 0–100 km/h in s 8.4

Fuel consumption

Urban in l/100 km 8.0-7.9
Extra–urban in l/100 km 6.0-5.9
Combined in l/100 km 6.7-6.6
CO2 combined emissions in g/km 154-151
Tank capacity, approx. in l 60

Wheels

Tyre dimensions front 225/55 R17 97 V
Tyre dimensions rear 225/55 R17 97 V
Wheel dimensions and material front 8 J x 17 inches, light-alloy
Wheel dimensions and material rear 8 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,700
Max. permissible weight in kg 2,190
Permitted load in kg 565
Permitted axle load front/rear in kg 980/1,275
Luggage capacity min. (seats up or roof down) in l 520
Luggage capacity max. (seats down or roof up) in l 1,600
Trailer load 8% (braked) in kg 1,700
Trailer load 12% (braked) in kg 1,600
Trailer load unbraked in kg 750

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 185 (252)/5,200
Engine torque (Nm) at 1/min 350/1,450-4,800
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 6.1

Fuel consumption

Urban in l/100 km 8.0-7.6
Extra–urban in l/100 km 5.6
Combined in l/100 km 6.5-6.3
CO2 combined emissions in g/km 147-144
Tank capacity, approx. in l 60

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 8 J x 17 inches, light-alloy
Wheel dimensions and material rear 8 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,765
Max. permissible weight in kg 2,255
Permitted load in kg 565
Permitted axle load front/rear in kg 1,050/1,275
Luggage capacity min. (seats up or roof down) in l 520
Luggage capacity max. (seats down or roof up) in l 1,600
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,700
Trailer load unbraked in kg 750

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 185 (252)/5,200-6,500
Engine torque (Nm) at 1/min 350/1,450-4,800
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 6.2

Fuel consumption

Urban in l/100 km 8.5-8.3
Extra–urban in l/100 km 6.3-6.2
Combined in l/100 km 7.1-7.0
CO2 combined emissions in g/km 161-159
Tank capacity, approx. in l 60

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 8 J x 17 inches, light-alloy
Wheel dimensions and material rear 8 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,745
Max. permissible weight in kg 2,240
Permitted load in kg 570
Permitted axle load front/rear in kg 1,025/1,275
Luggage capacity min. (seats up or roof down) in l 520
Luggage capacity max. (seats down or roof up) in l 1,600
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,700
Trailer load unbraked in kg 750

Engine

Cylinders/valves 6/4
Capacity in ccm 2,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 240 (326)/5,500-6.500
Engine torque (Nm) at 1/min 450/1,500-5,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 5.1

Fuel consumption

Urban in l/100 km 9.9-9.7
Extra–urban in l/100 km 6.4-6.3
Combined in l/100 km 7.7-7.6
CO2 combined emissions in g/km 176-172
Tank capacity, approx. in l 60

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 8 J x 17 inches, light-alloy
Wheel dimensions and material rear 8 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,805
Max. permissible weight in kg 2,295
Permitted load in kg 565
Permitted axle load front/rear in kg 1,090/1,275
Luggage capacity min. (seats up or roof down) in l 520
Luggage capacity max. (seats down or roof up) in l 1,600
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800
Trailer load unbraked in kg 750

Engine

Cylinders/valves 6/4
Capacity in ccm 2,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 240 (326)/5,500-6.500
Engine torque (Nm) at 1/min 450/1,500-5,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 5.0

Fuel consumption

Urban in l/100 km 10.6-10.3
Extra–urban in l/100 km 6.7-6.5
Combined in l/100 km 8.1-7.9
CO2 combined emissions in g/km 185-181
Tank capacity, approx. in l 60

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 8 J x 17 inches, light-alloy
Wheel dimensions and material rear 8 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,690 [1,735]
Max. permissible weight in kg 2,185 [2,210]
Permitted load in kg 570 [550]
Permitted axle load front/rear in kg 970/1,300 [970/1,300]
Luggage capacity min. (seats up or roof down) in l 520 [520]
Luggage capacity max. (seats down or roof up) in l 1,600 [1,600]
Trailer load 8% (braked) in kg 1,700 [1,700]
Trailer load 12% (braked) in kg 1,600 [1,600]
Trailer load unbraked in kg 750 [750]

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 110 (150)/4,000
Engine torque (Nm) at 1/min 320/1,500-3,000
Compression ratio : 1 16.5

Performance

Top speed in km/h 210 [210]
Acceleration 0–100 km/h in s 9.4 [9.3]

Fuel consumption

Urban in l/100 km 6.0 [5.6-5.5]
Extra–urban in l/100 km 4.6-4.5 [4.4-4.3]
Combined in l/100 km 5.2-5.1 [4.9-4.8]
CO2 combined emissions in g/km 135-133 [128-125]
Tank capacity, approx. in l 57

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 8 J x 17 inches, light-alloy
Wheel dimensions and material rear 8 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,705 [1,735]
Max. permissible weight in kg 2,200 [2,220]
Permitted load in kg 570 [560]
Permitted axle load front/rear in kg 970/1,300 [970/1,300]
Luggage capacity min. (seats up or roof down) in l 520 [520]
Luggage capacity max. (seats down or roof up) in l 1,600 [1,600]
Trailer load 8% (braked) in kg 1,800 [1,800]
Trailer load 12% (braked) in kg 1,600 [1,600]
Trailer load unbraked in kg 750 [750]

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 140 (190)/4,000
Engine torque (Nm) at 1/min 400/1,750-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 230 [226]
Acceleration 0–100 km/h in s 7.9 [7.8]

Fuel consumption

Urban in l/100 km 6.0-5.8 [5.4-5.3]
Extra–urban in l/100 km 4.6-4.5 [4.5-4.4]
Combined in l/100 km 5.1-5.0 [4.9-4.7]
CO2 combined emissions in g/km 135-131 [128-125]
Tank capacity, approx. in l 57

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 8 J x 17 inches, light-alloy
Wheel dimensions and material rear 8 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,815
Max. permissible weight in kg 2,285
Permitted load in kg 545
Permitted axle load front/rear in kg 1,025/1,310
Luggage capacity min. (seats up or roof down) in l 520
Luggage capacity max. (seats down or roof up) in l 1,600
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,600
Trailer load unbraked in kg 750 [750]

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 140 (190)/4,000
Engine torque (Nm) at 1/min 400/1,750-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 225
Acceleration 0–100 km/h in s 7.8

Fuel consumption

Urban in l/100 km 6.2-6.1
Extra–urban in l/100 km 4.8-4.7
Combined in l/100 km 5.4-5.2
CO2 combined emissions in g/km 141-137
Tank capacity, approx. in l 57

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 8 J x 17 inches, light-alloy
Wheel dimensions and material rear 8 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,790
Max. permissible weight in kg 2,285
Permitted load in kg 570
Permitted axle load front/rear in kg 1,030/1,310
Luggage capacity min. (seats up or roof down) in l 520
Luggage capacity max. (seats down or roof up) in l 1,600
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800
Trailer load unbraked in kg 750

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 190 (258)/4,000
Engine torque (Nm) at 1/min 560/1,500-3,000
Compression ratio : 1 16.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 5.7

Fuel consumption

Urban in l/100 km 6.7-6.6
Extra–urban in l/100 km 5.4-5.3
Combined in l/100 km 5.8-5.7
CO2 combined emissions in g/km 153-150
Tank capacity, approx. in l 57

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 8 J x 17 inches, light-alloy
Wheel dimensions and material rear 8 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,845
Max. permissible weight in kg 2,340
Permitted load in kg 570
Permitted axle load front/rear in kg 1,080/1,310
Luggage capacity min. (seats up or roof down) in l 520
Luggage capacity max. (seats down or roof up) in l 1,600
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800
Trailer load unbraked in kg 750

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 190 (258)/4,000
Engine torque (Nm) at 1/min 560/1,500-3,000
Compression ratio : 1 16.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 5.4

Fuel consumption

Urban in l/100 km 7.3-7.2
Extra–urban in l/100 km 5.6-5.5
Combined in l/100 km 6.2-6.1
CO2 combined emissions in g/km 163-161
Tank capacity, approx. in l 57

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 8 J x 17 inches, light-alloy
Wheel dimensions and material rear 8 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,855
Max. permissible weight in kg 2,350
Permitted load in kg 570
Permitted axle load front/rear in kg 1,095/1,310
Luggage capacity min. (seats up or roof down) in l 520
Luggage capacity max. (seats down or roof up) in l 1,600
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800
Trailer load unbraked in kg 750

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 230 (313)/4,400
Engine torque (Nm) at 1/min 630/1,500-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.9

Fuel consumption

Urban in l/100 km 7.8-7.7
Extra–urban in l/100 km 5.7-5.6
Combined in l/100 km 6.4
CO2 combined emissions in g/km 169-167
Tank capacity, approx. in l 57

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 8 J x 17 inches, light-alloy
Wheel dimensions and material rear 8 J x 17 inches, light-alloy
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

FUEL CONSUMPTION AND CO2 EMISSIONS OF THE BMW 3 SERIES GRAN TURISMO.

BMW 340i Gran Turismo:
Fuel consumption in l/100 km (combined): 7.7–7.6
CO2 emissions in g/km (combined): 176–172



The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.



Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2



The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.


Read more

FUEL CONSUMPTION AND CO2 EMISSIONS OF THE BMW 3 SERIES GRAN TURISMO.

  • BMW 340i Gran Turismo:
    Fuel consumption in l/100 km (combined): 7.7–7.6
    CO2 emissions in g/km (combined): 176–172

    Diesel engines available until 09/2020

    The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2

    The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.
