BMW 2 SERIES GRAN TOURER: ENGINES & TECHNICAL DATA.

The most important facts and figures about the BMW 2 Series Gran Tourer at a glance: Find out here about engines, performance, weight, fuel consumption, CO2 emissions, dimensions, boot capacity and much more.

Read more
THE 2BMW 2 SERIES GRAN TOURER: ENGINES & TECHNICAL DATA.

TECHNICAL DATA BMW 2 SERIES GRAN TOURER.

Weight

Unladen weight EU in kg 1,500-1,550
Max. permissible weight in kg 2,055-2,160
Permitted load in kg 630-685
Permitted axle load front/rear in kg 1,010/1,055-1,210
Luggage capacity min. (seats up) in l 560
Luggage capacity max. (seats down) in l 1,905
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,100
Trailer load 12% (braked) in kg 1,100

Engine

Cylinders/valves 3/4
Capacity in ccm 1,499
Stroke/bore in mm 94.6/82.0
Engine power* in kW (hp) at 1/min 80 (109)/4,300-6,500
Engine torque (Nm) at 1/min 190/1,380-3,800
Compression ratio : 1 11.0

Performance

Top speed in km/h 188
Acceleration 0–100 km/h in s 11.9-11.7

Fuel consumption

Combined in l/100 km 6.8-6.2
CO2 combined emissions in g/km 156-141
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 205/60 R16 96 W XL
Tyre dimensions rear 205/60 R16 96 W XL
Wheel dimensions and material front 7 J x 16 inches, light-alloy
Wheel dimensions and material rear 7 J x 16 inches, light-alloy

Weight

Unladen weight EU in kg 1,505-1,555 [1,530-1,580]
Max. permissible weight in kg 2,060-2,155 [2,090-2,180]
Permitted load in kg 630-675 [635-675]
Permitted axle load front/rear in kg 1,015/1,055-1,210 [1,045/1,055-1,205]
Luggage capacity min. (seats up) in l 560 [560]
Luggage capacity max. (seats down) in l 1,905 [1,905]
Trailer load (unbraked) in kg 750 [750]
Trailer load 8% (braked) in kg 1,500 [1,500]
Trailer load 12% (braked) in kg 1,500 [1,500]

Engine

Cylinders/valves 3/4
Capacity in ccm 1,499
Stroke/bore in mm 94.6/82.0
Engine power* in kW (hp) at 1/min 100 (136)/4,500-6,500
Engine torque (Nm) at 1/min 220/1,500-4,100
Compression ratio : 1 11.0

Performance

Top speed in km/h 205 [205]
Acceleration 0–100 km/h in s 9.8-9.5 [9.8-9.6]

Fuel consumption

Combined in l/100 km 6.8-6.2 [6.8-6.2]
CO2 combined emissions in g/km 155-141 [155-140]
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 205/60 R16 96 W XL
Tyre dimensions rear 205/60 R16 96 W XL
Wheel dimensions and material front 7 J x 16 inches, light-alloy
Wheel dimensions and material rear 7 J x 16 inches, light-alloy

Weight

Unladen weight EU in kg 1,570-1,620
Max. permissible weight in kg 2,140-2,235
Permitted load in kg 645-690
Permitted axle load front/rear in kg 1,080/1,070-1,220
Luggage capacity min. (seats up) in l 560
Luggage capacity max. (seats down) in l 1,905
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,500
Trailer load 12% (braked) in kg 1,500

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power* in kW (hp) at 1/min 131 (178)/4,750-5,500
Engine torque (Nm) at 1/min 280/1,350-4,200
Compression ratio : 1 11.0

Performance

Top speed in km/h 222
Acceleration 0–100 km/h in s 7.7-7.5

Fuel consumption

Combined in l/100 km 7.0-6.3
CO2 combined emissions in g/km 160-144
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 205/55 R17 95 W XL
Tyre dimensions rear 205/55 R17 95 W XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,565-1,610 [1,580-1,615]
Max. permissible weight in kg 2,130-2,220 [2,155-2,225]
Permitted load in kg 640-685 [650-685]
Permitted axle load front/rear in kg 1,055/1,090-1,240 [1,075/1,090-1,240]
Luggage capacity min. (seats up) in l 560 [560]
Luggage capacity max. (seats down) in l 1,905 [1,905]
Trailer load (unbraked) in kg 750 [750]
Trailer load 8% (braked) in kg 1,500 [1,500]
Trailer load 12% (braked) in kg 1,500 [1,500]

Engine

Cylinders/valves 3/4
Capacity in ccm 1,496
Stroke/bore in mm 90.0/84.0
Engine power* in kW (hp) at 1/min 85 (116)/4,000
Engine torque (Nm) at 1/min 270/1,750-2,250
Compression ratio : 1 16.5

Performance

Top speed in km/h 192 [192]
Acceleration 0–100 km/h in s 11.8-11.5 [11.8-11.5]

Fuel consumption

Combined in l/100 km 5.3-4.8 [5,5-5,0]
CO2 combined emissions in g/km 139-126 [144-131]
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 205/60 R16 96 W XL
Tyre dimensions rear 205/60 R16 96 W XL
Wheel dimensions and material front 7 J x 17 inches, light-alloy
Wheel dimensions and material rear 7 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,600-1,650 [1,620-1,680]
Max. permissible weight in kg 2,165-2,265 [2,200-2,265]
Permitted load in kg 640-690 [655-690]
Permitted axle load front/rear in kg 1,090/1,090-1,245 [1,125-1,130/1,090-1,245]
Luggage capacity min. (seats up) in l 560 [560]
Luggage capacity max. (seats down) in l 1,905 [1,905]
Trailer load (unbraked) in kg 750 [750]
Trailer load 8% (braked) in kg 1,500 [1,500]
Trailer load 12% (braked) in kg 1,500 [1,500]

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power* in kW (hp) at 1/min 100-110 (136-150)/4,000
Engine torque (Nm) at 1/min 350/1,750-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 198-207 [200-207]
Acceleration 0–100 km/h in s 9.4-10.0 [9.4-10.0]

Fuel consumption

Combined in l/100 km 5.3-4.8 [5.6-5.1]
CO2 combined emissions in g/km 140-126 [147-133]
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 205/55 R17 95 W XL
Tyre dimensions rear 205/55 R17 95 W XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,690-1,740
Max. permissible weight in kg 2,260-2,360
Permitted load in kg 645-695
Permitted axle load front/rear in kg 1,150/1,130-1,285
Luggage capacity min. (seats up) in l 560
Luggage capacity max. (seats down) in l 1,905
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power* in kW (hp) at 1/min 110 (150)/4,000
Engine torque (Nm) at 1/min 350/1,750-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 205
Acceleration 0–100 km/h in s 9.6-9.4

Fuel consumption

Combined in l/100 km 5.8-5.3
CO2 combined emissions in g/km 153-139
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 205/55 R17 95 W XL
Tyre dimensions rear 205/55 R17 95 W XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,635-1,685
Max. permissible weight in kg 2,220-2,310
Permitted load in kg 660-700
Permitted axle load front/rear in kg 1,125/1,100-1,250
Luggage capacity min. (seats up) in l 560
Luggage capacity max. (seats down) in l 1,905
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,500
Trailer load 12% (braked) in kg 1,500

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power* in kW (hp) at 1/min 140 (190)/4,000
Engine torque (Nm) at 1/min 400/1,750-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 220
Acceleration 0–100 km/h in s 8.2-8.0

Fuel consumption

Combined in l/100 km -
CO2 combined emissions in g/km -
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 205/55 R17 95 W XL
Tyre dimensions rear 205/55 R17 95 W XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,695-1,745
Max. permissible weight in kg 2,280-2,375
Permitted load in kg 660-705
Permitted axle load front/rear in kg 1,145/1,140-1,290
Luggage capacity min. (seats up) in l 560
Luggage capacity max. (seats down) in l 1,905
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power* in kW (hp) at 1/min 140 (190)/4,000
Engine torque (Nm) at 1/min 400/1,750-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 218
Acceleration 0–100 km/h in s 8.0-7.8

Fuel consumption

Combined in l/100 km 5.8-5.3
CO2 combined emissions in g/km 153-140
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 205/55 R17 95 W XL
Tyre dimensions rear 205/55 R17 95 W XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW 220d xDrive Gran Tourer:
Fuel consumption in l/100 km (combined): 4.9–4.8
CO2 emissions in g/km (combined): 128–126

The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2

The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.
