BMW X5 G05 2018 Mineral White metallic three-quarter rear view driving

THE X5

BMW X5: ENGINES &
TECHNICAL DATA

THE X5BMW X5: ENGINES &amp;<br> TECHNICAL DATA

Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW X5.

Read more

TECHNICAL DATA OF THE BMW X5.

Select model

Weight

Unladen weight EU in kg 2,175-2,250
Max. permissible weight in kg 2,840-3,050
Permitted load in kg 875-740
Permitted axle load front/rear in kg 1,320-1,355/1,670-1,870
Luggage capacity min. (seats up or roof down) in l 650-550
Luggage capacity max. (seats down or roof up) in l 1,870-1,770
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 3,500-2,500
Trailer load 12% (braked) in kg 3,500-2,500

Engine

Cylinders/valves 6/4
Capacity in ccm 2,998
Stroke/bore in mm 94,6/82,0
Engine power in kW (hp) at 1/min 245 (333)/5,500-6,250
Engine torque (Nm) at 1/min 450/1,600-4,800
Compression ratio : 1 11.0

Performance

Top speed in km/h 243
Acceleration 0–100 km/h in s 5.9-5.7
Top speed electrical in km/h -

Fuel consumption

Combined in l/100 km 10.7-8.9
CO2 combined emissions in g/km 244-204
Electricity consumption combined in kWh/100km -
Tank capacity, approx. in l 83

Wheels

Tyre dimensions front 255/55 R18 109 W XL
Tyre dimensions rear 255/55 R18 109 W XL
Wheel dimensions and material front 8.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (PS) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (PS) -
Combined torque Nm -

Weight

Unladen weight EU in kg 2,335
Max. permissible weight in kg 2,995
Permitted load in kg 735
Permitted axle load front/rear in kg 1,430/1,645
Luggage capacity min. (seats up or roof down) in l 650
Luggage capacity max. (seats down or roof up) in l 1,870
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 3,500-2,700
Trailer load 12% (braked) in kg 3,500-2,700

Engine

Cylinders/valves 8/4
Capacity in ccm 4.395
Stroke/bore in mm 88.3/89.0
Engine power in kW (hp) at 1/min 390 (530)/5,500-6,000
Engine torque (Nm) at 1/min 750/1,800-4,600
Compression ratio : 1 10.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.3
Top speed electrical in km/h -

Fuel consumption

Combined in l/100 km 12.3-11.5
CO2 combined emissions in g/km 281-263
Electricity consumption combined in kWh/100km -
Tank capacity, approx. in l 83

Wheels

Tyre dimensions front 275/40 R21 107 Y XL
Tyre dimensions rear 315/35 R21 111 Y XL
Wheel dimensions and material front 9.5 J x 21 inches, light-alloy
Wheel dimensions and material rear 10.5 J x 21 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (PS) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (PS) -
Combined torque Nm -

Weight

Unladen weight EU in kg 2,145-2,245
Max. permissible weight in kg 2,820-2,940
Permitted load in kg 750
Permitted axle load front/rear in kg 1,300-1,285/1,785-1,610
Luggage capacity min. (seats up or roof down) in l 650-550
Luggage capacity max. (seats down or roof up) in l 1,870-1,770
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,700-1,700
Trailer load 12% (braked) in kg 2,700-1,700

Engine

Cylinders/valves 4/4
Capacity in ccm 1.995
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 155-170 (211-231)/4,400
Engine torque (Nm) at 1/min 450/1,500-3,000
Compression ratio : 1 16.5

Performance

Top speed in km/h 216-222
Acceleration 0–100 km/h in s 9.0-7.5
Top speed electrical in km/h -

Fuel consumption

Combined in l/100 km 8.5-7.1
CO2 combined emissions in g/km 223-186
Electricity consumption combined in kWh/100km -
Tank capacity, approx. in l 80

Wheels

Tyre dimensions front 255/55 R18 109 W XL
Tyre dimensions rear 255/55 R18 109 W XL
Wheel dimensions and material front 8.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (PS) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (PS) -
Combined torque Nm -

Weight

Unladen weight EU in kg 2,265-2,345
Max. permissible weight in kg 2,940-3,160
Permitted load in kg 750-890
Permitted axle load front/rear in kg 1,375-1,390/1,665-1,885
Luggage capacity min. (seats up or roof down) in l 650-550
Luggage capacity max. (seats down or roof up) in l 1,870-1,770
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 3,500-1,700
Trailer load 12% (braked) in kg 3,500-1,700

Engine

Cylinders/valves 6/4
Capacity in ccm 2.993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 183-210 (249-286)/3,250-4,400 - 4,000 [218 (297)/4,000*]
Engine torque (Nm) at 1/min 650/1,500-2,500 [680/1,500-2,500*]
Compression ratio : 1 16.5

Performance

Top speed in km/h 225-235
Acceleration 0–100 km/h in s 7.4-6.1
Top speed electrical in km/h -

Fuel consumption

Combined in l/100 km 8.0-6.6
CO2 combined emissions in g/km 210-173
Electricity consumption combined in kWh/100km -
Tank capacity, approx. in l 80

Wheels

Tyre dimensions front 255/55 R18 109 W XL
Tyre dimensions rear 255/55 R18 109 W XL
Wheel dimensions and material front 8.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (PS) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (PS) -
Combined torque Nm -

Weight

Unladen weight EU in kg 2,275-2,360
Max. permissible weight in kg 3,170-2,940
Permitted load in kg 885-740
Permitted axle load front/rear in kg 1,375-1,395/1,635-1,885
Luggage capacity min. (seats up or roof down) in l 550-650
Luggage capacity max. (seats down or roof up) in l 1,770-1,870
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 3,500-2,500
Trailer load 12% (braked) in kg 3,500-2,500

Engine

Cylinders/valves 6/4
Capacity in ccm 2.993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 250 (340)/4,400
Engine torque (Nm) at 1/min 700/1.750-2.250
Compression ratio : 1 16.5

Performance

Top speed in km/h 245
Acceleration 0–100 km/h in s 5.6-5.5
Top speed electrical in km/h -

Fuel consumption

Combined in l/100 km 8.1-6.9
CO2 combined emissions in g/km 213-180
Electricity consumption combined in kWh/100km -
Tank capacity, approx. in l 80

Wheels

Tyre dimensions front 255/55 R18 109 W XL
Tyre dimensions rear 255/55 R18 109 W XL
Wheel dimensions and material front 8.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (PS) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (PS) -
Combined torque Nm -

Weight

Unladen weight EU in kg 2,510
Max. permissible weight in kg 3,150
Permitted load in kg 715
Permitted axle load front/rear in kg 1,390/1,810
Luggage capacity min. (seats up or roof down) in l 500
Luggage capacity max. (seats down or roof up) in l 1,720
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,700
Trailer load 12% (braked) in kg 2,700

Engine

Cylinders/valves 6/4
Capacity in ccm 2.998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 155-210 (211-286)/5,000-6,000 - 5,000-6,500
Engine torque (Nm) at 1/min 450/1,600-3,500 - 1,600-3,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 205-235
Acceleration 0–100 km/h in s 6.6-5.6
Top speed electrical in km/h 135

Fuel consumption

Combined in l/100 km 1.7-1.2
CO2 combined emissions in g/km 40-27
Electricity consumption combined in kWh/100km 27.7-24.3
Tank capacity, approx. in l 69

Wheels

Tyre dimensions front 265/50 R19 110 W XL
Tyre dimensions rear 265/50 R19 110 W XL
Wheel dimensions and material front 9 J x 19 inches, light-alloy
Wheel dimensions and material rear 9 J x 19 inches, light-alloy

Range and charging

Electric range in km 77-88
Growth capacity of lithium–ion battery in kWh 24.0
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h 5.2
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h 7.1

Electric engine

Electric engine power kW (PS) at 1/min 83 (113)/3,170
Electric Engine torque (Nm) at 1/min 265/100-2,500

Combined system power

Combined power kW (PS) 235-290 (320-394)
Combined torque Nm 600
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Fuel consumption, electricity consumption and CO2 emissions of the BMW X5.

BMW X5 xDrive40i:
Fuel consumption in l/100 km (combined): 10.7–8.9
CO2 emissions in g/km (combined): 244–204

BMW X5 xDrive45e:
Fuel consumption in l/100 km (combined): 1.7–1.2
CO2 emissions in g/km (combined): 40–27
Electricity consumption combined in kWh/100 km: 27.7–24.3

Official data on fuel consumption, CO2 emissions, power consumption and electric range were determined in accordance with the mandatory measurement procedure and comply with Regulation (EU) 715/2007 valid at the time of type approval. In case of a range, figures in the WLTP take into account any optional equipment. For newly type-tested vehicles since 01.01.2021, the official data no longer exist according to NEDC, but only according to WLTP. For more information on the WLTP and NEDC measurement procedures, see www.bmw.de/wltp

For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html

Read more

Fuel consumption, electricity consumption and CO2 emissions of the BMW X5.

  • BMW X5 xDrive40i:
    Fuel consumption in l/100 km (combined): 10.7–8.9
    CO2 emissions in g/km (combined): 244–204

    BMW X5 xDrive45e*:
    Fuel consumption in l/100 km (combined): 1.7–1.2
    CO2 emissions in g/km (combined): 40–27
    Electricity consumption combined in kWh/100 km: 27.7–24.3

    *At temperatures below 0 degrees Celsius, purely electric driving mode of this plug-in hybrid will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few kilometers.

    Official data on fuel consumption, CO2 emissions, power consumption and electric range were determined in accordance with the mandatory measurement procedure and comply with Regulation (EU) 715/2007 valid at the time of type approval. In case of a range, figures in the WLTP take into account any optional equipment. For newly type-tested vehicles since 01.01.2021, the official data no longer exist according to NEDC, but only according to WLTP. For more information on the WLTP and NEDC measurement procedures, see www.bmw.de/wltp.

    For more information on the official fuel consumption and official specific CO2 emissions of new passenger cars, see the ‘Guide to Fuel Consumption, CO2 Emissions, and Electricity Consumption of New Passenger Cars’, which is available free of charge at all sales outlets, from Deutsche AutomobilTreuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern- Scharnhausen, and at www.dat.de/co2
