Engines and technical data for the new BMW M340i xDrive Touring

THE 3Engines and technical data for the new BMW M340i xDrive Touring

Sporting genes: explore the powerful petrol and diesel engines as well as hybrid motors together with dimensions and other technical data of the BMW M340i xDrive Touring.

Read more

TECHNICAL DATA.

Weight
Unladen weight EU in kg
1,845
Max. permissible weight in kg
2.365
Permitted load in kg
595
Permitted axle load front/rear in kg
935/1,095
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
6/4
Capacity in ccm
2,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
275 (374)/5,500-6,500
Engine torque (Nm) at 1/min
500/1,850-5,500
Compression ratio : 1
10.2
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
4.5
Fuel consumption
Urban in l/100 km
9.7-9.2
Extra–urban in l/100 km
6.3-5.9
Combined in l/100 km
7.6-7.2
CO2 combined emissions in g/km
172-163
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/45 R18 95 Y XL
Tyre dimensions rear
255/40 R18 99 Y XL
Wheel dimensions and material front
7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear
8.5 J x 18 inches, light-alloy
Weight
Unladen weight EU in kg
1,955
Max. permissible weight in kg
2,415
Permitted load in kg
535
Permitted axle load front/rear in kg
1,155/1,360
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
6/4
Capacity in ccm
2,993
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
250 (340)/4,400
Engine torque (Nm) at 1/min
700/1,750-2,250
Compression ratio : 1
16.5
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
4.6
Fuel consumption
Urban in l/100 km
7.8-7.3
Extra–urban in l/100 km
4.7-4.3
Combined in l/100 km
5.8-5.4
CO2 combined emissions in g/km
153-143
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/45 R18 95Y XL
Tyre dimensions rear
255/40 R18 99Y XL
Wheel dimensions and material front
7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear
8.5 J x 18 inches, light-alloy

Fuel consumption and CO2 emissions.

  • BMW M340i xDrive Touring:
    Fuel consumption in l/100 km (combined): 7.6–7.2
    CO2 emissions in g/km (combined): 172-163

    BMW M340d xDrive Touring(2)*:
    Fuel consumption in l/100 km (combined): 5.8–5.4
    CO2 emissions in g/km (combined): 153–143

    * Available from 04/2020. Data is preliminary.

    The values of the vehicles labeled with (2) are preliminary.

    The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2

    The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.
