TECHNICAL DATA FOR THE BMW M135 xDRIVE.

¹
Powertrain type	Petrol
Power in kW (hp)	90 (122)
Torque in Nm	230
Transmission	7-speed, automatic
Drivetrain	Front-wheel drive

¹
Cylinders	3
Displacement in cm³	1,499
Nominal power in kW (hp)/1/min	90 (122) / 3,900 - 6,500
Nominal torque in Nm/1/min	230 / 1,500 - 3,600


Acceleration 0–100 km/h in s	9.8
Top speed in km/h	210

^{1 ,}²
Fuel consumption, combined WLTP in l/100 km	6.4–5.9
CO2 emissions, combined WLTP in g/km	146–135
Pass-by noise in dB(A)	66 ⁵
Stationary noise level in dB(A) / 1/min	78 / 3,750 ⁵


4,361 mm
1,800 mm
1,459 mm
Length in mm	4,361
Width in mm	1,800
Height in mm	1,459
Width incl. mirrors (driver / passenger side) in mm	2,072
Wheelbase in mm	2,670
Vehicle curb weight in kg ³	1,465
Permissible gross weight in kg	1,960
Payload in kg	570
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	- / 75
Luggage capacity in l	380–1,200
Tank capacity in l	49

¹
Powertrain type	Petrol – 48 Volt Mild-Hybrid
Power in kW (hp)	125 (170) ⁶
Torque in Nm	280 ⁶
Transmission	7-speed, automatic
Drivetrain	Front-wheel drive

¹
Cylinders	3
Displacement in cm³	1,499
Nominal power in kW (hp)/1/min	115 (156) / 4,700 - 6,500
Nominal torque in Nm/1/min	240 / 1,500 - 4,400


(Nominal) power/30-minutes-power in kW (hp)	15 (20) / -
(Nominal) torque in Nm	55


Acceleration 0–100 km/h in s	7.8
Top speed in km/h	226

^{1 ,}²
Fuel consumption, combined WLTP in l/100 km	5.8–5.3
CO2 emissions, combined WLTP in g/km	132–121
Pass-by noise in dB(A)	67 ⁵
Stationary noise level in dB(A) / 1/min	78 / 3,750 ⁵

⁷
Battery capacity in kWh	0.9


4,361 mm
1,800 mm
1,459 mm
Length in mm	4,361
Width in mm	1,800
Height in mm	1,459
Width incl. mirrors (driver / passenger side) in mm	2,072
Wheelbase in mm	2,670
Vehicle curb weight in kg ³	1,500
Permissible gross weight in kg	1,990
Payload in kg	565
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	- / 75
Luggage capacity in l	300–1,135
Tank capacity in l	49

¹
Powertrain type	Petrol – 48 Volt Mild-Hybrid
Power in kW (hp)	160 (218) ⁶
Torque in Nm	360 ⁶
Transmission	7-speed, automatic
Drivetrain	All-wheel drive

¹
Cylinders	4
Displacement in cm³	1,998
Nominal power in kW (hp)/1/min	150 (204) / 5,000 - 6,500
Nominal torque in Nm/1/min	320 / 1,500 - 4,000


(Nominal) power/30-minutes-power in kW (hp)	15 (20) / -
(Nominal) torque in Nm	55


Acceleration 0–100 km/h in s	6.3
Top speed in km/h	246

^{1 ,}²
Fuel consumption, combined WLTP in l/100 km	6.4–5.9
CO2 emissions, combined WLTP in g/km	145–134
Pass-by noise in dB(A)	65 ⁵
Stationary noise level in dB(A) / 1/min	74 / 3,750 ⁵

⁷
Battery capacity in kWh	0.9


4,361 mm
1,800 mm
1,459 mm
Length in mm	4,361
Width in mm	1,800
Height in mm	1,459
Width incl. mirrors (driver / passenger side) in mm	2,072
Wheelbase in mm	2,670
Vehicle curb weight in kg ³	1,605
Permissible gross weight in kg	2,085
Payload in kg	555
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	- / 75
Luggage capacity in l	300–1,135
Tank capacity in l	49

¹
Powertrain type	Petrol
Power in kW (hp)	221 (300)
Torque in Nm	400
Transmission	7-speed, automatic
Drivetrain	All-wheel drive

¹
Cylinders	4
Displacement in cm³	1,998
Nominal power in kW (hp)/1/min	221 (300) / 5,750 - 6,500
Nominal torque in Nm/1/min	400 / 2,000 - 4,500


Acceleration 0–100 km/h in s	4.9
Top speed in km/h	250

^{1 ,}²
Fuel consumption, combined WLTP in l/100 km	8.3–7.6
CO2 emissions, combined WLTP in g/km	188–173
Pass-by noise in dB(A)	67 ⁵
Stationary noise level in dB(A) / 1/min	73 / 3,750 ⁵


4,361 mm
1,800 mm
1,459 mm
Length in mm	4,361
Width in mm	1,800
Height in mm	1,459
Width incl. mirrors (driver / passenger side) in mm	2,072
Wheelbase in mm	2,670
Vehicle curb weight in kg ³	1,625
Permissible gross weight in kg	2,100
Payload in kg	550
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	- / 75
Luggage capacity in l	380–1,200
Tank capacity in l	49

¹
Powertrain type	Diesel
Power in kW (hp)	110 (150)
Torque in Nm	360
Transmission	7-speed, automatic
Drivetrain	Front-wheel drive

¹
Cylinders	4
Displacement in cm³	1,995
Nominal power in kW (hp)/1/min	110 (150) / 3,750 - 4,000
Nominal torque in Nm/1/min	360 / 1,500 - 2,500


Acceleration 0–100 km/h in s	8.3
Top speed in km/h	222

^{1 ,}²
Fuel consumption, combined WLTP in l/100 km	5.1–4.6
CO2 emissions, combined WLTP in g/km	133–122
Pass-by noise in dB(A)	66 ⁵
Stationary noise level in dB(A) / 1/min	75 / 3,000 ⁵


4,361 mm
1,800 mm
1,459 mm
Length in mm	4,361
Width in mm	1,800
Height in mm	1,459
Width incl. mirrors (driver / passenger side) in mm	2,072
Wheelbase in mm	2,670
Vehicle curb weight in kg ³	1,540
Permissible gross weight in kg	2,050
Payload in kg	585
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	- / 75
Luggage capacity in l	380–1,200
Tank capacity in l	49

¹
Powertrain type	Diesel – 48 Volt Mild-Hybrid
Power in kW (hp)	120 (163) ⁶
Torque in Nm	400 ⁶
Transmission	7-speed, automatic
Drivetrain	Front-wheel drive

¹
Cylinders	4
Displacement in cm³	1,995
Nominal power in kW (hp)/1/min	110 (150) / 3,750 - 4,000
Nominal torque in Nm/1/min	360 / 1,500 - 2,500


(Nominal) power/30-minutes-power in kW (hp)	15 (20) / -
(Nominal) torque in Nm	55


Acceleration 0–100 km/h in s	7.9
Top speed in km/h	222

^{1 ,}²
Fuel consumption, combined WLTP in l/100 km	4.7–4.3
CO2 emissions, combined WLTP in g/km	122–112
Pass-by noise in dB(A)	65 ⁵
Stationary noise level in dB(A) / 1/min	76 / 3,000 ⁵

⁷
Battery capacity in kWh	0.9


4,361 mm
1,800 mm
1,459 mm
Length in mm	4,361
Width in mm	1,800
Height in mm	1,459
Width incl. mirrors (driver / passenger side) in mm	2,072
Wheelbase in mm	2,670
Vehicle curb weight in kg ³	1,570
Permissible gross weight in kg	2,060
Payload in kg	565
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	- / 75
Luggage capacity in l	300–1,135
Tank capacity in l	49

1 Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 1151/2017. Unleaded RON 91 and higher with a maximum ethanol content of 25% (E25) may also be used. BMW recommends RON 95 fuel. For high-performance automobiles, BMW recommends RON 98 fuel.

2 Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp

3 The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.

4 Trailer load depends on the vehicle options

5 The values measured in accordance with UN/ECE Regulation No. 51/EU Regulation 540/2014 are rounded.

6 Composed of combustion engine drive (specified nominal value) and electric drive (up to specified nominal value).

7 The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Find out more

Fuel consumption and CO2 emissions.

BMW M135 xDrive: Fuel consumption, combined WLTP in l/100 km: 8.3–7.6; CO2 emissions, combined WLTP in g/km: 188–173

The new BMW 116 is expected to be available in November 2024. The figures for the BMW 116 are therefore provisional and have not yet been officially confirmed.
