BMW iX2 (U10): Engines & technical data

BMW iX2 xDrive30^[1]: Energy consumption, combined WLTP in kWh/100 km: 17.7 - 17.6; Electric range, WLTP in km: 417 - 421

^[1] Range depends on various factors, in particular: individual driving style, route characteristics, outside temperature, heating/air conditioning, pre-conditioning.

TECHNICAL DATA FOR THE BMW iX2.


Powertrain type	Electric
Power in kW (hp)	150 (204)
Torque in Nm	250
Transmission	1-speed, automatic
Drivetrain	Front-wheel drive


(Nominal) power/30-minutes-power in kW (hp)	150 (204) / 68 (92)
(Nominal) torque in Nm	250


Acceleration 0–100 km/h in s	8.6
Electric top speed in km/h	170

¹
CO2 emissions, combined WLTP in g/km	0
Energy consumption, combined WLTP in kWh/100 km	16.9–15.3
Electric range, WLTP in km ²	439–478
Pass-by noise in dB(A)	66 ⁶

³
Battery capacity in kWh	64.8
Maximum charging power AC in kW	11 / 22
Charging time AC 0–100% in h	6:30 / 3:45
Maximum charging power DC in kW	130
Charging time DC 10–80% in h	0:29


4,554 mm
1,845 mm
1,560 mm
Length in mm	4,554
Width in mm	1,845
Height in mm	1,560
Width incl. mirrors (driver / passenger side) in mm	2,104
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	1,960
Permissible gross weight in kg	2,460
Payload in kg	575
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	- / 80
Luggage capacity in l	525–1,400


Powertrain type	Electric
Power in kW (hp)	230 (313) ⁷
Torque in Nm	494
Transmission	1-speed, automatic
Drivetrain	All-wheel drive


(Nominal) power/30-minutes-power in kW (hp)	225 (306)/104 (141)
(Nominal) torque in Nm	494


Acceleration 0–100 km/h in s	5.6
Electric top speed in km/h	180

¹
CO2 emissions, combined WLTP in g/km	0
Energy consumption, combined WLTP in kWh/100 km	17.7 - 17.6
Electric range, WLTP in km ²	417 - 421
Pass-by noise in dB(A)	65 ⁶

⁸
CO2e emissions up to vehicle handover (Scope 1, 2, 3up), approx. in t	14.6
Secondary raw material content of the entire vehicle, approx. in %	16

³
Battery capacity in kWh	64.8
Maximum charging power AC in kW	11 / 22
Charging time AC 0–100% in h	6:30
Maximum charging power DC in kW	130
Charging time DC 10–80% in h	0:29


4,554 mm
1,845 mm
1,560 mm
Length in mm	4,554
Width in mm	1,845
Height in mm	1,560
Width incl. mirrors (driver / passenger side) in mm	2,104 (1,055 / 1,049)
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	2,095
Permissible gross weight in kg	2,605
Payload in kg	585
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	- / 80
Luggage capacity in l	525 - 1,400

⁹
Powertrain type	Diesel
Power in kW (hp)	110 (150)
Torque in Nm	360
Transmission	7-speed, automatic
Drivetrain	Front-wheel drive

⁹
Cylinders	4
Displacement in cm³	1,995
Nominal power in kW (hp)/1/min	110 (150)/3,750–4,000
Nominal torque in Nm/1/min	360 / 1,500 - 2,500


Acceleration 0–100 km/h in s	8.9
Top speed in km/h	210

^{9 ,}¹
Fuel consumption, combined WLTP in l/100 km	5.5–5.1
CO2 emissions, combined WLTP in g/km	144–133
Pass-by noise in dB(A)	67 ⁶
Stationary noise level in dB(A) / 1/min	74 / 3,000 ⁶


4,554 mm
1,845 mm
1,590 mm
Length in mm	4,554
Width in mm	1,845
Height in mm	1,590
Width incl. mirrors (driver / passenger side) in mm	2,104 (1,055 / 1,049)
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	1,675
Permissible gross weight in kg	2,170
Payload in kg	570
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	- / 80
Luggage capacity in l	560 - 1,470
Tank capacity in l	54

⁹
Powertrain type	Petrol
Power in kW (hp)	221 (300)
Torque in Nm	400
Transmission	7-speed, automatic
Drivetrain	All-wheel drive

⁹
Cylinders	4
Displacement in cm³	1,998
Nominal power in kW (hp)/1/min	221 (300) / 5,750 - 6,500
Nominal torque in Nm/1/min	400 / 2,000 - 4,500


Acceleration 0–100 km/h in s	5.4
Top speed in km/h	250

^{9 ,}¹
Fuel consumption, combined WLTP in l/100 km	8.1–7.7
CO2 emissions, combined WLTP in g/km	187–175
Pass-by noise in dB(A)	67 ⁶
Stationary noise level in dB(A) / 1/min	76 / 3,750 ⁶


Battery capacity in kWh	0.9


4,567 mm
1,845 mm
1,575 mm
Length in mm	4,567
Width in mm	1,845
Height in mm	1,575
Width incl. mirrors (driver / passenger side) in mm	2,104 (1,055 / 1,049)
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	1,770
Permissible gross weight in kg	2,270
Payload in kg	575
Luggage capacity in l	560 - 1,470
Tank capacity in l	54

⁹
Powertrain type	Petrol – 48 Volt Mild-Hybrid
Power in kW (hp)	125 (170) ¹⁰
Torque in Nm	280 ¹⁰
Transmission	7-speed, automatic
Drivetrain	Front-wheel drive

⁹
Cylinders	3
Displacement in cm³	1,499
Nominal power in kW (hp)/1/min	115 (156) / 4,700 - 6,500
Nominal torque in Nm/1/min	240 / 1,500 - 4,400


(Nominal) power/30-minutes-power in kW (hp)	15 (20) / -
(Nominal) torque in Nm	55


Acceleration 0–100 km/h in s	55
Top speed in km/h	213

^{9 ,}¹
Fuel consumption, combined WLTP in l/100 km	6.2–5.7
CO2 emissions, combined WLTP in g/km	140–128
Pass-by noise in dB(A)	66 ⁶
Stationary noise level in dB(A) / 1/min	72 / 3,750 ⁶

⁸
CO2e emissions up to vehicle handover (Scope 1, 2, 3up), approx. in t	9.2
Secondary raw material content of the entire vehicle, approx. in %	17

³
Battery capacity in kWh	0.9


4,554 mm
1,845 mm
1,590 mm
Length in mm	4,554
Width in mm	1,845
Height in mm	1,590
Width incl. mirrors (driver / passenger side) in mm	2,104 (1,055 / 1,049)
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	1,645
Permissible gross weight in kg	2,150
Payload in kg	580
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	- / 80
Luggage capacity in l	515 - 1,400
Tank capacity in l	54

1 Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp

2 Range depends on various factors, in particular: individual driving style, route characteristics, outside temperature, heating/air conditioning, pre-conditioning.

3 The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.

4 The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.

5 Trailer load depends on the vehicle options

6 The values measured in accordance with UN/ECE Regulation No. 51/EU Regulation 540/2014 are rounded.

7 Temporary uprating <10 seconds in excess of specified nominal value

8 according to the life cycle assessment study at start of production, see BMW Vehicle Footprint Report for details

9 Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 1151/2017. Unleaded RON 91 and higher with a maximum ethanol content of 25% (E25) may also be used. BMW recommends RON 95 fuel. For high-performance automobiles, BMW recommends RON 98 fuel.

10 Composed of combustion engine drive (specified nominal value) and electric drive (up to specified nominal value).

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Find out more

Consumption and CO2 emissions.

BMW iX2 xDrive30^[1]: Energy consumption, combined WLTP in kWh/100 km: 17.7 - 17.6; Electric range, WLTP in km: 417 - 421

The figures for performance, consumption and CO2 emissions refer to vehicles with standard transmission. Values in square brackets apply to vehicles with automatic transmission.
