BMW 3 SERIES TOURING: ENGINES & TECHNICAL DATA

THE 3BMW 3 SERIES TOURING: ENGINES & TECHNICAL DATA

TECHNICAL DATA.

Weight
Unladen weight EU in kg
1,645
Max. permissible weight in kg
2.135
Permitted load in kg
565
Permitted axle load front/rear in kg
975/1,260
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,600
Trailer load 12% (braked) in kg
1,600
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
135 (184)/5,000-6,500
Engine torque (Nm) at 1/min
300/1,350-4,000
Compression ratio : 1
11.0
Performance
Top speed in km/h
230
Acceleration 0–100 km/h in s
7.5
Fuel consumption
Urban in l/100 km
7.0-6.8
Extra–urban in l/100 km
5.6-5.1
Combined in l/100 km
6.1-5.7
CO2 combined emissions in g/km
138-130
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,670
Max. permissible weight in kg
2.185
Permitted load in kg
590
Permitted axle load front/rear in kg
985/1,280
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,600
Trailer load 12% (braked) in kg
1,600
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
190 (258)/5,000-6,500
Engine torque (Nm) at 1/min
400/1,550-4,400
Compression ratio : 1
10.2
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.9
Fuel consumption
Urban in l/100 km
7.5-7.1
Extra–urban in l/100 km
5.3-5.1
Combined in l/100 km
6.1-5.9
CO2 combined emissions in g/km
139-134
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,730
Max. permissible weight in kg
2,260
Permitted load in kg
605
Permitted axle load front/rear in kg
1,050/1,295
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
190 (258)/5,000-6,500
Engine torque (Nm) at 1/min
400/1,550-4,400
Compression ratio : 1
10.2
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.8
Fuel consumption
Urban in l/100 km
7.8-7.3
Extra–urban in l/100 km
5.7-5.4
Combined in l/100 km
6.5-6.1
CO2 combined emissions in g/km
148-139
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,650 [1,660]
Max. permissible weight in kg
2,160 [2,180]
Permitted load in kg
585 [595]
Permitted axle load front/rear in kg
980/1,270 [985/1,280]
Luggage capacity min. (seats up or roof down) in l
500 [500]
Luggage capacity max. (seats down or roof up) in l
1,510 [1,510]
Trailer load (unbraked) in kg
750 [750]
Trailer load 8% (braked) in kg
1,600 [1,800]
Trailer load 12% (braked) in kg
1,600 [1,800]
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
110 (150)/4,000
Engine torque (Nm) at 1/min
320/1,500-3,000
Compression ratio : 1
16.5
Performance
Top speed in km/h
217 [215]
Acceleration 0–100 km/h in s
8.9 [8.8]
Fuel consumption
Urban in l/100 km
5.7-5.3 [5.2-4.8]
Extra–urban in l/100 km
4.3-4.0 [4.4-4.1]
Combined in l/100 km
4.8-4.5 [4.7-4.4]
CO2 combined emissions in g/km
127-118 [123-114]
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,655 [1,675]
Max. permissible weight in kg
2,180 [2,190]
Permitted load in kg
600 [590]
Permitted axle load front/rear in kg
985/1,280 [995/1,285]
Luggage capacity min. (seats up or roof down) in l
500 [500]
Luggage capacity max. (seats down or roof up) in l
1,510 [1,510]
Trailer load (unbraked) in kg
750 [750]
Trailer load 8% (braked) in kg
1,600 [1,800]
Trailer load 12% (braked) in kg
1,600 [1,800]
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
140 (190)/4,000
Engine torque (Nm) at 1/min
400/1,750-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
229 [230]
Acceleration 0–100 km/h in s
7.5 [7.1]
Fuel consumption
Urban in l/100 km
5.7-5.3 [5.3-4.8]
Extra–urban in l/100 km
4.3-4.0 [4.4-4.2]
Combined in l/100 km
4.8-4.5 [4.8-4.4]
CO2 combined emissions in g/km
127-117 [125-115]
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,735
Max. permissible weight in kg
2,255
Permitted load in kg
595
Permitted axle load front/rear in kg
1,055/1,300
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
140 (190)/4,000
Engine torque (Nm) at 1/min
400/1,750-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
225
Acceleration 0–100 km/h in s
7.4
Fuel consumption
Urban in l/100 km
5.4-5.2
Extra–urban in l/100 km
4.6-4.3
Combined in l/100 km
4.9-4.6
CO2 combined emissions in g/km
129-121
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7,5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7,5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,790
Max. permissible weight in kg
2,305
Permitted load in kg
590
Permitted axle load front/rear in kg
1,075/1.325
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
6/4
Capacity in ccm
2,993
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
195 (265)/4,000
Engine torque (Nm) at 1/min
580/1,750-2,750
Compression ratio : 1
16.5
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.6
Fuel consumption
Urban in l/100 km
6.6-6.2
Extra–urban in l/100 km
4.8-4.5
Combined in l/100 km
5.5-5.2
CO2 combined emissions in g/km
144-136
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,835
Max. permissible weight in kg
2,350
Permitted load in kg
590
Permitted axle load front/rear in kg
1,105/1,340
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
6/4
Capacity in ccm
2,993
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
195 (265)/4,000
Engine torque (Nm) at 1/min
580/1,750-2,750
Compression ratio : 1
16.5
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.4
Fuel consumption
Urban in l/100 km
6.4-6.3
Extra–urban in l/100 km
5.1-4.7
Combined in l/100 km
5.6-5.3
CO2 combined emissions in g/km
147-138
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,845
Max. permissible weight in kg
2.365
Permitted load in kg
595
Permitted axle load front/rear in kg
935/1,095
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
6/4
Capacity in ccm
2,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
275 (374)/5,500-6,500
Engine torque (Nm) at 1/min
500/1,850-5,500
Compression ratio : 1
10.2
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
4.5
Fuel consumption
Urban in l/100 km
9.7-9.2
Extra–urban in l/100 km
6.3-5.9
Combined in l/100 km
7.6-7.2
CO2 combined emissions in g/km
172-163
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/45 R18 95 Y XL
Tyre dimensions rear
255/40 R18 99 Y XL
Wheel dimensions and material front
7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear
8.5 J x 18 inches, light-alloy
Weight
Unladen weight EU in kg
1,955
Max. permissible weight in kg
2,415
Permitted load in kg
535
Permitted axle load front/rear in kg
1,155/1,360
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
6/4
Capacity in ccm
2,993
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
250 (340)/4,400
Engine torque (Nm) at 1/min
700/1,750-2,250
Compression ratio : 1
16.5
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
4.6
Fuel consumption
Urban in l/100 km
7.8-7.3
Extra–urban in l/100 km
4.7-4.3
Combined in l/100 km
5.8-5.4
CO2 combined emissions in g/km
153-143
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/45 R18 95Y XL
Tyre dimensions rear
255/40 R18 99Y XL
Wheel dimensions and material front
7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear
8.5 J x 18 inches, light-alloy

Fuel consumption and CO2 emissions.

  • BMW 330i Touring:
    Fuel consumption in l/100 km (combined): 6.1–5.9
    CO2 emissions in g/km (combined): 139–134

    The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2

    The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.
