BMW M5 Automobiles Overview
Request Test Drive

The key facts and figures for the BMW 5 Series Sedan M Automobiles at a glance: find out all about engines, consumption, CO2 emissions and dimensions of the various BMW M5 models. Compare impressive performance data such as displacement, hp, Nm and acceleration – and discover which of these three exceptional sports sedans suits you best.

Read more

ENGINES AND TECHNICAL DATA OF THE BMW 5 SERIES SEDAN M AUTOMOBILES.

Select model

Weight

Unladen weight EU in kg 1,970
Max. permissible weight in kg 2,440
Permitted load in kg 545
Permitted axle load front/rear in kg 1,215/1,260
Luggage capacity min. (seats up) in l 530
Luggage capacity max. (seats down) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,000
Trailer load 12% (braked) in kg 2,000

Engine

Cylinders/valves 8/4
Capacity in ccm 4,395
Stroke/bore in mm 88.3/89.0
Engine power in kW (hp) at 1/min 460 (625)/6,000
Engine torque (Nm) at 1/min 750/1,800-5,860
Compression ratio : 1 10.0

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 3.3

Fuel consumption

Urban in l/100 km 16.9-16.7
Extra-urban in l/100 km 8.1-7.8
Combined in l/100 km 11.3-11.1
CO2 combined emissions in g/km 259-253
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 275/35 ZR20 (102 Y) XL
Tyre dimensions rear 285/35 ZR20 (104 Y) XL
Wheel dimensions and material front 9.5 J x 20 inches, light-alloy
Wheel dimensions and material rear 10.5 J x 20 inches, light-alloy

Weight

Unladen weight EU in kg 1,970
Max. permissible weight in kg 2,440
Permitted load in kg 545
Permitted axle load front/rear in kg 1,215/1,260
Luggage capacity min. (seats up) in l 530
Luggage capacity max. (seats down) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,000
Trailer load 12% (braked) in kg 2,000

Engine

Cylinders/valves 8/4
Capacity in ccm 4,395
Stroke/bore in mm 88.3/89.0
Engine power in kW (hp) at 1/min 441 (600)/6,000
Engine torque (Nm) at 1/min 750/1,800-5,600
Compression ratio : 1 10.0

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 3.4

Fuel consumption

Urban in l/100 km 16.9-16.7
Extra-urban in l/100 km 8.1-7.8
Combined in l/100 km 11.3-11.1
CO2 combined emissions in g/km 259-253
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 275/40 ZR19 (105 Y) XL
Tyre dimensions rear 285/40 ZR19 (107 Y) XL
Wheel dimensions and material front 9.5 J x 19 inches, light-alloy
Wheel dimensions and material rear 10.5 J x 19 inches, light-alloy

Weight

Unladen weight EU in kg 1,990
Max. permissible weight in kg 2,560
Permitted load in kg 645
Permitted axle load front/rear in kg 1,260/1,365
Luggage capacity min. (seats up) in l 530
Luggage capacity max. (seats down) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,000
Trailer load 12% (braked) in kg 2,000

Engine

Cylinders/valves 8/4
Capacity in ccm 4.395
Stroke/bore in mm 88.3/89.0
Engine power in kW (hp) at 1/min 390 (530)/5,500-6,000
Engine torque (Nm) at 1/min 750/1,800-4,600
Compression ratio : 1 10.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 3.8

Fuel consumption

Urban in l/100 km 14.2-13.7
Extra-urban in l/100 km 8.6-8.5
Combined in l/100 km 10.7-10.4
CO2 combined emissions in g/km 250-235
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 245/40 R19 98 Y XL
Tyre dimensions rear 275/35 R19 100 Y XL
Wheel dimensions and material front 8Jx19 inches, light-alloy
Wheel dimensions and material rear 9Jx19 inches, light-alloy
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW M5 CS:
Fuel consumption in l/100 km (combined): 11.3–11.1
CO2 emissions in g/km (combined): 258–253

BMW M5 Competition:
Fuel consumption in l/100 km (combined): 11.3–11.1
CO2 emissions in g/km (combined): 259–254

BMW M5:
Fuel consumption in l/100 km (combined): 11.3–11.1
CO2 emissions in g/km (combined): 259–254

BMW M550i xDrive Sedan:
Fuel consumption in l/100 km (combined): 10.7–10.4
CO2 emissions in g/km (combined): 243–238

The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2

The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.

Read more
​

Fuel consumption and CO2 emissions.

  • BMW M5 Competition:
    Fuel consumption in l/100 km (combined): 11.3–11.1
    CO2 emissions in g/km (combined): 259–254

    BMW M5:
    Fuel consumption in l/100 km (combined): 11.3–11.1
    CO2 emissions in g/km (combined): 259–254

    BMW M550i xDrive Sedan:
    Fuel consumption in l/100 km (combined): 10.7–10.4
    CO2 emissions in g/km (combined): 243–238

    The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2

    The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.
