BMW Z4 Roadster, technical data

THE Z4

BMW Z4: ENGINES & TECHNICAL DATA

THE Z4BMW Z4: ENGINES & TECHNICAL DATA

TECHNICAL DATA OF THE BMW Z4 ROADSTER.

Select model

Weight

Unladen weight EU in kg 1,420 [1,430]
Max. permissible weight in kg 1,725 [1,740]
Permitted load in kg 305 [310]
Permitted axle load front/rear in kg 830/935 [830/935]
Luggage capacity in l 281
Trailer load 8% (braked) in kg -

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 145 (197)/4,500-6,500
Engine torque (Nm) at 1/min 320/1,450-4,200
Compression ratio : 1 10.2

Performance

Top speed in km/h 241 [240]
Acceleration 0–100 km/h in s 6.8 [6.6]

Fuel consumption

Urban in l/100 km 9.2 [7.3]
Extra-urban in l/100 km 5.5 [5.4]
Combined in l/100 km 6.9 [6.1]
CO2 combined emissions in g/km 157 [139]
Electricity consumption combined in kWh/100km -
Tank capacity, approx. in l 52

Wheels

Tyre dimensions front 225/50 R17 94W
Tyre dimensions rear 225/50 R17 98W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 17 inches, light-alloy

BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW Z4 Roadster M40i:
Fuel consumption in l/100 km (combined): x.x
CO2 emissions in g/km (combined): xxx


The illustrations show optional equipment.


The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.


Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2.


The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.


Read more

Fuel consumption and CO2 emissions.

  • BMW Z4 Roadster M40i:
    Fuel consumption in l/100 km (combined): 7.4
    CO2 emissions in g/km (combined): 168

    The illustrations show optional equipment.

    The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2.

    The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.
