THE BMW 4 SERIES GRAN COUPÉ: ENGINES & TECHNICAL DATA.

The key facts and figures on the BMW 4 Series Gran Coupé at a glance: engines, consumption, CO2 emissions and dimensions. Check out all the performance data such as displacement, horsepower, torque and acceleration – and find out which engine best meets your needs.

Read more
THE 4THE BMW 4 SERIES GRAN COUPÉ: ENGINES & TECHNICAL DATA.
BMW 4 Series Gran Coupé

TECHNICAL DATA OF THE BMW 4 SERIES GRAN COUPÉ.

Select model

Weight

Unladen weight EU in kg 1,695
Max. permissible weight in kg 2,175
Permitted load in kg 555
Permitted axle load front/rear in kg 1,015/1,245
Luggage capacity min. (seats up) in l 470
Luggage capacity max. (seats down) in l 1,290
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 235
Acceleration 0–100 km/h in s 7.9

Fuel consumption

Combined in l/100 km 7.3-6.6
CO2 combined emissions in g/km 166-150
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/55 R17 101 Y XL
Tyre dimensions rear 225/55 R17 101 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,720
Max. permissible weight in kg 2,200
Permitted load in kg 555
Permitted axle load front/rear in kg 1,025/1,255
Luggage capacity min. (seats up) in l 470
Luggage capacity max. (seats down) in l 1,290
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 180 (245)/4,500-6,500
Engine torque (Nm) at 1/min 400/1,600-4,000
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 6.2

Fuel consumption

Combined in l/100 km 7.6-6.8
CO2 combined emissions in g/km 173-156
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/55 R17 101 Y XL
Tyre dimensions rear 225/55 R17 101 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,775
Max. permissible weight in kg 2,255
Permitted load in kg 555
Permitted axle load front/rear in kg 1,090/1,255
Luggage capacity min. (seats up) in l 470
Luggage capacity max. (seats down) in l 1,290
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 180 (245)/4,500-6,500
Engine torque (Nm) at 1/min 400/1,600-4,000
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 6.1

Fuel consumption

Combined in l/100 km 7.9-7.1
CO2 combined emissions in g/km 180-162
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/55 R17 101 Y XL
Tyre dimensions rear 225/55 R17 101 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,900
Max. permissible weight in kg 2,380
Permitted load in kg 555
Permitted axle load front/rear in kg 1,145/1,325
Luggage capacity min. (seats up) in l 470
Luggage capacity max. (seats down) in l 1,290
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 6/4
Capacity in ccm 2,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 275 (374)/5,500-6,500
Engine torque (Nm) at 1/min 500/1,900-5,000
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.7

Fuel consumption

Combined in l/100 km 8.5-8.0
CO2 combined emissions in g/km 194-181
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 245/45 R18 100 Y XL
Tyre dimensions rear 245/45 R18 100 Y XL
Wheel dimensions and material front 8.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

Weight

Unladen weight EU in kg 1,780-1,745
Max. permissible weight in kg 2,260
Permitted load in kg 555-590
Permitted axle load front/rear in kg 1,060/1,310
Luggage capacity min. (seats up) in l 470
Luggage capacity max. (seats down) in l 1,290
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 120-140 (163-190)/4,000
Engine torque (Nm) at 1/min 400/1,750-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 224-235
Acceleration 0–100 km/h in s 8.3-7.3

Fuel consumption

Combined in l/100 km 5.4-4.8
CO2 combined emissions in g/km 141-126
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/55 R17 101 Y XL
Tyre dimensions rear 225/55 R17 101 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,835-1,805
Max. permissible weight in kg 2,315
Permitted load in kg 555-585
Permitted axle load front/rear in kg 1,105/1,315
Luggage capacity min. (seats up) in l 470
Luggage capacity max. (seats down) in l 1,290
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 140 (190)/4,000
Engine torque (Nm) at 1/min 400/1,750-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 233
Acceleration 0–100 km/h in s 7.8-7.6

Fuel consumption

Combined in l/100 km 5.7-5.1
CO2 combined emissions in g/km 150-133
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/55 R17 101 Y XL
Tyre dimensions rear 225/55 R17 101 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Fuel consumption and CO2 emissions of the BMW 4 Series Gran Coupé.

BMW M440i xDrive Gran Coupé:
Fuel consumption in l/100 km (combined): 8.5-8.0
CO2 emissions in g/km (combined): 194-181


Official data on fuel consumption and CO2 emissions were determined in accordance with the mandatory measurement procedure and comply with Regulation (EU) 715/2007 valid at the time of type approval. In case of a range, figures in the WLTP take into account any optional equipment. For newly type-tested vehicles since 01.01.2021, the official data no longer exist according to NEDC, but only according to WLTP. For more information on the WLTP and NEDC measurement procedures, see www.bmw.de/wltp.
